Motorola Call Boxes

Assure Instant Communication With Two-Way Radio Call Boxes

Added Safety and Convenience in Remote Locations
Communicate Without Wires or Monthly Operating Fees

Whether used within a corporation or college campus, recreational area, shopping center or transportation system, Call Boxes provide a swift and reliable way for employees, visitors and customers to communicate to a monitoring station. Two-way based Call Boxes, designed by Connectivity, allow for integration into most existing radio systems and provide direct access to personnel connected to the system. Connectivity's design allows for expansion of security coverage and can help improve response time without the need for additional personnel. Call Boxes provide an affordable and reliable way to communicate with and secure the most remote locations. Not only can Connectivity's Call Boxes integrate into most existing two-way radio systems, but they are also upgradeable should a user's radio frequency change. Built-in voice chips give audible instructions to users requiring assistance, and each unit has an automatic Call Box ID and location identifier so responding personnel can provide aid.

Motorola Call Boxes allow for integration into most existing radio systems and provide direct access to personnel connected to the system. Allows for expansion of security coverage and can help improve response time without the need for additional personnel. Includes a voice instruction message for the user, automatic call box ID and user location identifiers, a courtesy light, easy push-to-talk operation, a silent tamper alert broadcast to security, low battery alert, 40-day standby battery capacity, one 12-volt, 12 amp/hour rechargeable battery, call box keys and tamper resistant screw bits.

All Connectivity Call Boxes Include:

  • Voice Instruction Message for User
  • Automatically Announces Call Box ID and User Location
  • Courtesy Light
  • Easy Push-to-talk Operation
  • Silent Tamper Alert Broadcast to Security
  • Low Battery Alert
  • 40-day Standby Battery Capacity
  • One 12 Volt, 12 Amp/Hour Rechargeable Battery
  • Call Box Keys and Tamper-resistant Screw Bits
  • 1-Year Warranty on Call Box; 5-Year Warranty on Solar Panel Communicate

A1 Call Boxes

RRDN4362A

RRDN4362A - Solar A1 Call Box
The attractive A1 Call Box combines a unique design with rugged durability. It's field programmable to allow voice messages to be easily changed for special events. This solar-powered Call Box mounts on a wall, PVC or aluminum stanchion. The aluminum enclosure has a white powder-coating, is .090 inches thick and measures 13"H x 9.5"W x 6.5"D. Perfect for indoor and outdoor use, this Call Box provides protection against dust and falling rain. It includes an antenna and set of small reflective decals.


RRDN4363A

RRDN4363A - AC/DC A1 Call Box
The attractive A1 Call Box combines a unique design with rugged durability. It's field programmable to allow voice messages to be easily changed for special events. This AC/DC-powered Call Box mounts on a wall, PVC or aluminum stanchion. The aluminum enclosure has a white powder-coating, is .090 inches thick and measures 13"H x 9.5"W x 6.5"D. Perfect for indoor and outdoor use, this Call Box provides protection against dust and falling rain. It includes an antenna and set of small reflective decals.


RRDN4365A

RRDN4365A - Solar A1 Call Box with Aluminum Stanchion
The attractive A1 Call Box combines a unique design with rugged durability. This solar-powered Call Box is field programmable to allow voice messages to be easily changed for special events. The aluminum enclosure has a white powder-coating, is .090 inches thick and measures 13"H x 9.5"W x 6.5"D. The .090 inch thick aluminum stanchion measures 10'H x 10"W x 5"D. It includes four light openings, an internal 60,000CP blue strobe light, light-opening lens covers made of clear plastic and a 10-watt solar panel. This Call Box includes an antenna and set of small reflective decals.


A106.5 Call Boxes

RRDN4588A

RRDN4588A - Solar A106.5 Call Box
The Free-standing; 6 ½ Foot Tall lower-profile model does not include a strobe light and may be used for customer service applications as well security and public safety.

The RRDN4588A Call Box is ideal for golf courses, marinas, college campuses, and more. It includes a heavy-duty clear polycarbonate faceplate cover, activation ringer, and programmable voice message for the location announcement.

The solar-powered A106.5 includes a 5-watt panel and a 12-volt 12-amp-hour battery. Call boxes mount over your pre-installed pressure-treated in-ground piling. An optional aluminum base pedestal is available for hard surface installation.

The .090 thick, white powder-coated aluminum box measures 6.5' H x 10" W x 5" D. It includes an antenna and choice of reflective vinyl message decals, choice of "Assistance", Emergency" or simply "Call Box".


RRDN4589A

RRDN4589A - AC/DC A106.5 Call Box
The Free-standing; 6 ½ Foot Tall lower-profile model does not include a strobe light and may be used for customer service applications as well security and public safety.

The RRDN4589A Call Box is ideal for golf courses, marinas, college campuses, and more. It includes a heavy-duty clear polycarbonate faceplate cover, activation ringer, and programmable voice message for the location announcement.

The AC/DC powered A106.5 includes a charger and a 12-volt 12-amp-hour battery. Call boxes mount over your pre-installed pressure-treated in-ground piling. An optional aluminum base pedestal is available for hard surface installation.

The .090 thick, white powder-coated aluminum box measures 6.5' H x 10" W x 5" D. It includes an antenna and choice of reflective vinyl message decals, choice of "Assistance", Emergency" or simply "Call Box".

A144 Call Boxes

RRDN4590A

RRDN4590A - Solar A144 Call Box
At four feet tall, this solar-powered Call Box unit combines the flexibility of wall or pole mounting with convenient accessibility and the security of a strobe light to assist respondents. This unit is ideal for parking facilities including garages and remote lots, as well as hospitals, community swimming pools, stadiums, and factories. The white, powder-coated, aluminum enclosure is .090 inches thick and measures 4'H x 14"W x 7.5"D. It includes a 6-watt locator LED that converts to a strobe light when a Call Box is activated. This Call Box comes standard with a 10-watt solar panel and choice of large reflective vinyl message decal.


RRDN4591A

RRDN4591A - AC/DC A144 Call Box
At four feet tall, this solar-powered Call Box unit combines the flexibility of wall or pole mounting with convenient accessibility and the security of a strobe light to assist respondents. This unit is ideal for parking facilities including garages and remote lots, as well as hospitals, community swimming pools, stadiums, and factories. The white, powder-coated, aluminum enclosure is .090 inches thick and measures 4'H x 14"W x 7.5"D. It includes a 6-watt locator LED that converts to a strobe light when a Call Box is activated. This Call Box comes with a choice of large reflective vinyl message decal.

A1510 CALL BOXES

RRDN7777A - Solar A1510 Call Box

RRDN7778A Solar Powered A1510 Call Box
w/o Base Pedestal, with Public Address System (PA)

RRDN7779A AC/DC Powered A1510 Call Box
w/o Base Pedestal

RRDN7780A AC/DC Powered A1510 Call Box
w/o Base Pedestal, with Public Address System (PA)

A1410 Call Boxes

RRDN4369A

RRDN4369A - Solar A1410 Call Box
The A1410 Call Box features a self-standing design that complements today's leading-edge architecture. It's ideal for high-profile corporate campuses. The .090" thick aluminum stanchion with white, powder-coating measures 10'H x 14"W x 7.5"D. This solar-powered Call Box features a thick, clear Lexan faceplate cover and includes an activation ringer, antenna and set of large reflective decals. This Call Box also offers a 10-watt solar panel which provides additional charging power to allow the beacon/locator light to function 24 hours a day.


RRDN4370A

RRDN4370A - AC/DC A1410 Call Box
The A1410 Call Box features a self-standing design that complements today's leading-edge architecture. It's ideal for high-profile corporate campuses. The .090" thick aluminum stanchion with white, powder-coating measures 10'H x 14"W x 7.5"D. This AC/DC-powered Call Box features a thick, clear Lexan faceplate cover and includes an activation ringer, antenna and set of large reflective decals.

ACB Call Boxes

RRDN4367A

RRDN4367A - Solar ACB Call Box
The solar-powered ACB Call Box provides quick, push-to-talk communication. Because there is no door to open, it is easily accessible. It's ideal for making restaurant, hotel or taxicab reservations, or announcing a delivery at an entry door. The indoor/outdoor wall mount aluminum enclosure has a white powder-coating and is .090 inches thick. It measures 20"H x 14"W x 7.5"D and features a thick, clear Lexan faceplate cover. It includes an activation ringer, antenna and set of small reflective decals.


RRDN4368A

RRDN4368A - AC/DC ACB Call Box
The AC/DC-powered ACB Call Box provides quick, push-to-talk communication. Because there is no door to open, it is easily accessible. It's ideal for making restaurant, hotel or taxicab reservations, or announcing a delivery at an entry door. The indoor/outdoor wall mount aluminum enclosure has a white powder-coating and is .090 inches thick. It measures 20"H x 14"W x 7.5"D and features a thick, clear Lexan faceplate cover. It includes an activation ringer, antenna and set of small reflective decals.
